775 Dc Motor for Power Tools Low Price Motor 12v 24v Dc Gear Motor
Product Description
775 DC Motor for Power Tools Low Price Motor 12V 24V DC Motor
Product Details
Customization available: Motor specifications and shaft lengths can be tailored to specific requirements.
Reference Drawing
⚡ RS-755 H Series
⚡ RS-775 H Series
Technical Specifications
| PMDC MOTOR TECHNICAL DATA | |||||||||||
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-770H 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81 / 826.2 | 111.8 | 115 | 666.9 / 6802 | |
| RS-775H 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4 / 452.9 | 13.35 | 4.07 | 245.7 / 2506 | |
Are you a trading company or manufacturer?
We are a factory specializing in micro DC motors and DC gear motors for more than 14 years.
What are the payment terms for new customers?
We accept online assurance orders, which allow payment via Master Card, Visa, etc. Customers can also pay via PayPal or TT.
Can you customize the motor for me?
Yes, we can customize a suitable motor according to specific customer requirements if you cannot find a standard model on our website.
Do you have certificates for the motors?
Yes, we have CE, FCC, ISO, and other relevant certificates. We can apply for additional certifications if required.
How is your Quality Control?
We have professional inspection staff for every production process. Completed motors undergo rigorous testing using hardness testers, 2.5D image testers, salt spray chambers, life testers, temperature test machines, and noise testers.
Is technical support available for motor selection?
Our engineering team provides comprehensive support to ensure the selected motor meets the specific torque, speed, and voltage requirements of your application.
