Shunli Vibration Dc Gear Motor 3V 6V 12V 1.4-1.6A 65RPM 75RPM 85RPM Hight Torque Coin Dc Gear Motor for Smart Lock
Product Description
🔥 Promotion
⚙️ Product Description
📊 Gearbox Technical Data
| Ratio | 241k |
| Max. Rated Torque | 1.5 ~ 2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4 ~ 5 Kgf.cm |
| Gearbox Efficiency | 45% ~ 60% |
⚡ Gearmotor Technical Performance
| Model | Ratio | Voltage (V) | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed(RPM) | Current(mA) | Speed(RPM) | Current(mA) | Torque (Kgf.cm) | Current(mA) | Torque (Kgf.cm) | |||
| GM2240 | 1:241 | 4.5 VDC | 52 | ≤ 50 | 40 | ≤ 120 | 1.8 | ≤ 350 | 0.18 |
| GM2240 | 1:241 | 4.5 VDC | 58 | ≤ 65 | 50 | ≤ 130 | 2.4 | ≤ 680 | 2.0 |
| GM2240 | 1:241 | 4.5 VDC | 68 | 75 | 56 | ≤ 140 | 2.6 | ≤ 750 | 2.2 |
🔹 PMDC Motor Technical Data
| Model | Voltage | No-Load Speed | No-Load Current | Rated Speed | Rated Torque | Stall Current |
|---|---|---|---|---|---|---|
| SL-N20-04510500 | 4.5VDC | 10500 RPM | ≤ 30mA | 8250 RPM | 2.0 gf.cm | ≤ 300mA |
| SL-N20-04514000 | 4.5VDC | 14000 RPM | ≤ 40mA | 12000 RPM | 2.5 gf.cm | ≤ 680mA |
| SL-N20-04516500 | 4.5VDC | 16500 RPM | ≤ 50mA | 13500 RPM | 2.5 gf.cm | ≤ 750mA |
🚀 Application Fields
⭐ Quality & Trust
🏭 Why Choose Our Factory
1. Manufacturing Expertise
We are a factory specializing in producing motors for more than 14 years. Our professional R&D team and mature management ensure a high-quality manufacturing process and a pleasant experience for our partners.
2. Strict Quality Control
To ensure superior quality, every step from material reception to final shipment is carefully checked. Quality is the foundation of our long-term development.
❓ Frequently Asked Questions
Are you a trading company or a manufacturer?
We are a specialized factory. We have focused on micro DC motors and DC gear motors for more than 14 years.
What are the available payment terms for new customers?
We support multiple payment methods including Online Assurance Orders (Visa, Master Card), PayPal, and TT (Telegraphic Transfer).
Can you provide customized motor solutions?
Yes, if you cannot find a suitable motor on our website, we can customize technical specifications according to your specific requirements.
Do your motors carry official certifications?
Yes, our motors are compliant with CE, FCC, ISO, and other standards. We can apply for additional certifications if your market requires them.
How do you ensure product quality?
We employ professional inspection staff at every production stage. Finished products undergo rigorous testing using Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, and Noise Testers.
Do you provide samples before bulk orders?
Yes, we provide samples to ensure the technical performance meets your application needs before moving to mass production.
