SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W
Product Description
SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W
Product Description
Key Performance Highlights:
- High-speed operation up to 17,500 RPM
- Efficient 11.51W output power
- Stable 4.5V DC nominal voltage
- Durable PMDC construction for industrial use
| Model | Rated Voltage (V) | No-Load | Rated | Stall | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Operating Range | Nominal | Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (mN.m) | Power (W) | Current (mA) | Torque (mN.m) | |
| RF-370CA-061700 | 6.0~24.0 | 24 VDC | 1320 | 3 | 1000 | 8 | 0.98 | 0.1 | 260 | 4.02 |
| RC-370CH-20123 | 3.0~6.0 | 6 VDC | 8000 | 70 | 6878 | 420 | 2.4 | 1.71 | 2550 | 17 |
| RC-370SH-4730 | 3.0~5.0 | 4.5 VDC | 17500 | 550 | 15199 | 3630 | 7.2 | 11.51 | 24000 | 55 |
| RC-370SH-18139 | 6.0~12.0 | 12 VDC | 10000 | 130 | 8439 | 700 | 5.8 | 5.17 | 3800 | 37.5 |
Applications & Diversity
Frequently Asked Questions
What is the nominal voltage for the SRC-370SH-4730?
The nominal voltage is 4.5V DC, with a functional operating range between 3.0V and 5.0V.
How fast does this motor run under no-load conditions?
The SRC-370SH-4730 model reaches a high speed of approximately 17,500 RPM when no load is applied.
What is the maximum output power of this PMDC motor?
This specific motor model provides a robust output power of 11.51W.
What are the typical applications for the 370 series motors?
These motors are versatile and commonly used in security systems, smart home devices, electronic tools, and personal care products.
Does the 370 series offer different specifications?
Yes, the series includes multiple variants like RF-370CA and RC-370CH, offering different speed and voltage combinations to suit various technical requirements.
What is the stall torque of the 4730 model?
The stall torque for the 4730 model is rated at 55 mN.m (approximately 561 gf.cm).
