Small Size High Power High Rpm 12v 24v Gear Motor for Vacuum Cleaner/cordless Power Tools/sewing Machine
Product Description
Small size high power high rpm 12v 24v gear motor for vacuum cleaner/cordless power tools/sewing machine
| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage(V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m | W | A | mN.m | ||||
| RS-550H | 23128R | 6.0~24.0 | 24VDC | 4500 | 0.1 | 3932 | 0.39 | 25.7 | 10.6 | 4.8 | 204 |
| 6034 | 6.0~12.0 | 12VDC | 16000 | 1.12 | 13613 | 4.96 | 25.6 | 40.36 | 48.89 | 281.4 | |
| RS-555H | 3540 | 6.0~12.0 | 12VDC | 7800 | 0.3 | 6708 | 1.84 | 21.9 | 15.35 | 11.31 | 156 |
| 23100 | 6.0~24.0 | 24VDC | 7000 | 0.14 | 6004 | 0.77 | 19.2 | 12.09 | 4.2 | 124.5 | |
✨ Versatile Usage: Suitable for vacuum cleaners, cordless power tools, sewing machines, and various industrial applications requiring high torque and reliable performance.
Are you a trading company or a manufacturer?
We are a factory specializing in micro DC motors and DC gear motors with more than 14 years of experience.
What is the payment term for new customers?
We accept online payments via Master Card, Visa, and other methods. Customers can also pay using PayPal or TT.
Can you customize a motor for me?
Yes, we can customize a suitable motor according to your specific requirements if you cannot find one on our list.
Do you have certificates for the motors?
Yes, we have CE, FCC, ISO, and other standard certificates. We can apply for other specific certificates if required.
How is your Quality Control process?
We have professional staff on every production line and use advanced testing machines such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, and Noise Testers.
What are the typical applications for these motors?
These motors are widely used in vacuum cleaners, cordless power tools, sewing machines, and other high-performance micro-machinery.
Looking forward to your feedback!
